Macintosh LC III
Macintosh LC III LC3

Logic Board Ports Power
Processor: 68030, 25 MHz
PMMU: integrated
FPU: opt. 68882
Data Path: 32-bit, 25 MHz
L1 Cache: 0.5K
L2 Cache: none
2nd Processor: none
Slots: 1 LC III PDS
USB:
ADB: 1
Video: DB-15
Floppy: none
SCSI: DB-25
Geoports: none
Ethernet: none
FireWire:
Mic Type: Omni
Other Ports: Printer, Modem, Speaker,
Max Watts: 50
Amps: 0.42
BTU per Hr: 171
Voltage: 100-240
Freq Range: 47-63 Hz
Battery Type: 3.6V lithium
Memory Video Memory
Logic Board: 4 MB
RAM Slots: 1, 72-pin SIMM
Min - Max RAM: 4 MB - 36 MB
Min RAM Speed: 80 ns
RAM Sizes: 1, 2, 4, 8, 16, 32 MB
Install in Groups of: 1
Resolution Video Memory
512K VRAM
(built in)
Video Memory
768K VRAM
(1x256K)
512 x 384 16-bit 16-bit
640 x 400 16-bit 16-bit
640 x 480 8-bit 16-bit
800 x 600 n/a-bit n/a-bit
832 x 624 8-bit 16-bit
1024 x 768 n/a-bit n/a-bit
1152 x 870 n/a-bit n/a-bit
1280 x 1024 n/a-bit n/a-bit

Notes: 512K VRAM SIMMs may be installed, but only 256K of each SIMM will be used.
Physical Software Storage
Introduced: 2/10/1993
Discontinued: 2/14/1994
Form Factor: LC
Gestalt ID: 27
Weight (lbs): 8.8
Dimensions (in): 2.9 H x 12.2 W x 15.3 D
Addressing Modes: 24-, 32-bit
Orig SSW: 7.1
Orig Enabler: System Enabler 003
ROM ID: $067C
ROM Ver: $22
ROM Size: 1MB
AppleTalk Ver: 57.0.4
Mac OS
Supported:
7.1
7.5
7.1.1 (Pro)
7.5.1
7.5.3
7.5.5
7.6
7.6.1
Floppy Size: 1.44MB
Floppy Inject: auto
Min. Int HD Size: 80-160MB
Int HD Interface: SCSI
Orig CD Speed n/a
Int CD Support:

Macintosh LC III • 25 MHz
