| Logic Board |
Ports |
Power |
| Processor: |
601, 80 MHz |
| PMMU: |
integrated |
| FPU: |
integrated |
| Data Path: |
64-bit, 40 MHz |
| L1 Cache: |
32K |
| L2 Cache: |
256K |
| 2nd Processor: |
none |
| Slots: |
3 NuBus, PDS filled |
|
| USB: |
|
| ADB: |
1 |
| Video: |
DB-15, HDI-45 |
| Floppy: |
none |
| SCSI: |
DB-25 |
| Geoports: |
2 |
| Ethernet: |
AAUI-15 |
| FireWire: |
|
| Mic Type: |
PlainTalk |
| Other Ports: |
Printer, Modem, Speaker,
|
|
| Max Watts: |
230 |
| Amps: |
1.90 |
| BTU per Hr: |
786.6 |
| Voltage: |
100-240 |
| Freq Range: |
50-60 Hz |
| Battery Type: |
3.6V lithium |
| Soft Power: |
yes |
| Pass Through: |
yes |
|
| Memory |
Video Memory |
| Logic Board: |
8 MB |
| RAM Slots: |
4, 72-pin SIMM |
| Min - Max RAM: |
8 MB - 136 MB |
| Min RAM Speed: |
80 ns |
| RAM Sizes: |
4, 8, 16, 32 MB |
| Install in Groups of: |
2 |
|
| Resolution |
Video Memory
DRAM (HDI-45)
(built in) |
Video Memory
1MB VRAM
(built in) |
Video Memory
2MB VRAM
(4x256K) |
| 512 x 384 |
16 -bit |
16-bit |
24-bit |
| 640 x 400 |
n/a-bit |
n/a-bit |
n/a-bit |
| 640 x 480 |
16-bit |
16-bit |
24-bit |
| 800 x 600 |
n/a-bit |
n/a-bit |
n/a-bit |
| 832 x 624 |
8-bit |
16-bit |
24-bit |
| 1024 x 768 |
n/a -bit |
8-bit |
16-bit |
| 1152 x 870 |
n/a-bit |
8-bit |
16-bit |
| 1280 x 1024 |
n/a-bit |
n/a-bit |
n/a-bit |
|
| Physical |
Software |
Storage |
| Introduced: |
1/3/1995 |
| Discontinued: |
1/6/1996 |
| Form Factor: |
IIvx |
| Gestalt ID: |
47 |
| Weight (lbs): |
25 |
| Dimensions (in): |
6 H x 13 W x 16.5 D |
|
| Addressing Modes: |
32-bit |
| Orig SSW: |
7.5 |
| Orig Enabler: |
PowerPC Enabler v1.1.1 |
| ROM ID: |
$077D |
| ROM Ver: |
n/a |
| ROM Size: |
4MB |
| AppleTalk Ver: |
n/a |
Mac OS
Supported: |
7.5
7.5.1
7.5.3
7.5.5
7.6
7.6.1
8.0
8.5
8.1 |
|
| Floppy Size: |
1.44MB |
| Floppy Inject: |
manual |
| Min. Int HD Size: |
350-700MB |
| Int HD Interface: |
SCSI |
| Orig CD Speed |
2x |
| Int CD Support: |
yes |
|
|
